Aeronaut Triple Thermic kit
Mukava rakennettava ja lennätettävä termiikki liidokki.
Kärkiväli: 2550mm
Pituus: 1220mm
Siipi pinta-ala: 47dm2
Paino: alk. 580g
Aeronaut Triple Speed - 112802
Leisurelysoaring in a thermal, high-starting with a bungee, taking part in a REScompetition or aerobatics – all this is possible with „Triple“. This completelynew concept combines an attractive V-tail fuselage (kit includes option for E-power) with three different wings. Each wing connects to the same fuselage.Powerful magnets hold the wings in place and let you change the setup easilyand quickly out in the field without tools.
Triple thermic has a wing-span of 255 cm and is equipped with ailerons and spoilers. The wing section is optimized for thermal soaring and provides excellent flying characteristics and performance.
The sleekglider fuselage offers very good aerodynamic characteristics. The fuselage forE-power has a wider nose to accept a 28-mm-outrunner and offers room for a 3s-LiPo with a capacity of 2.500 mAh. Both versions have a removable canopysecured by magnets and a removable cover on the belly of the fuselage whichgives access to the V-tail servos.
All threeversions of the Triple are all-wood designs, putting an emphasis on modelbuilding which has a long tradition at aero-naut. The fuselage is built up ofbalsa and light-ply, a well thought-out concept ensures a rapid buildingprocess and makes mistakes almost impossible. The V-tail consists of preciselylaser-cut parts and uses a special jig for good results. The wings useconventional ribs and spars, and just require a flat building board forconstruction. The trailing edges are built-up components and combine low weightwith good strength.
Even thosewho want to give model building a try will succeed with Triple and can buildtheir own individual glider or electric glider in a short period of time.Flying characteristics are excellent and make sure that even beginners or lessexperienced pilots will have fun. Clubs will find this model even an attractive project for youngermembers, who still learn how to build and fly.
- Motor: Ø 28mm, from ca. 150 Watt with suiting propeller & spinner
- ESC: 20-30A
- Battery: 3s– 2000mAh
- Servos: up to 11,5mm for aileron
- Wingspan [mm] 2.550
- Length [mm] 1.220
- Wing area [dm²] 47
- Weight [g] 58
